Dahua 6CE445XANR 4MP IR Starlight PTZ IP Security Camera with Analytics+ 45x Optical Zoom Lens with Night Vision

Name: Dahua 6CE445XANR 4MP IR Starlight PTZ IP Security Camera with Analytics+ 45x Optical Zoom Lens with Night Vision
SKU: 6CE445XANR
Availability: OutOfStock

$1,979.99

SKU: 6CE445XANR Categories: Dahua, Dahua Cameras, Dahua PoE Cameras, IP Cameras, Security Cameras Tags: 4k, Dahua, Starlight Analytics+ PTZ Network Camera

Out of stock

Dahua 6CE445XANR 4MP IR Starlight PTZ IP Security Camera with Analytics+ 45x Optical Zoom Lens with Night Vision

The Dahua 6CE445XANR 4 MP Starlight PTZ Dome camera features offers Analytics+ functions at the edge – performing complex real-time perimeter protection surveillance. The Dahua Analytics+ algorithms significantly improve accuracy and reliability as compared to standard intelligent features. The camera features a 1/2.8-in. CMOS STARVIS™ imager with a 45x optical zoom lens, and provides an all-in-one solution for capturing long-distance video surveillance for outdoor applications. The camera uses the H.265 video compression standard to improve encoding efficiency while preserving high-quality video. The PTZ camera is equipped with quick and accurate pan/tilt/zoom control and True WDR for applications with direct sunlight or glare.

Key Feature of Dahua 6CE445XANR
1/2.8-in. 4 MP Progressive-scan CMOS STARVIS™ Sensor
Powerful 45x Optical Zoom
Smart H.265+ and Smart H.264+ Dual Codec
4 MP at 30 fps Maximum Resolution
True Wide Dynamic Range
Starlight Technology for Ultra-low Light Sensitivity
Analytics+ Functions — Perimeter Protection
Intelligent Video System (IVS) with Auto-tracking
Maximum IR distance up to 250.0 m (820.21 ft)
ArcticPro Series Camera – Operational down to –40° C (–40° F)
IP67 Ingress Protection and IK10 Vandal Resistance Rating
Designed for Extreme Temperature Environments
Five-year Warranty (for products sold through authorized Dahua Dealers)

Dahua 6CE445XANR Features

Camera

Image Sensor 1/2.8-in. STARVIS™ CMOS
Effective Pixels 2560(H) x 1440(V), 4 MP
RAM/ROM 1024 MB / 128 MB
Scanning System Progressive
Electronic Shutter Speed 1/1 s to 1/30,000 s
Minimum Illumination Color: 0.005 lux at F1.6, B/W: 0.0005 lux at F1.6, 0 lux at F1.6 with IR on
IR Distance Distance up to 250.0 m (820.21 ft)
IR On/Off Control Auto, Manual
IR LEDs Six (6)

Lens

Focal Length 3.95 mm to 177.75 mm
Max. Aperture F1.6 to F4.95
Angle of View
Horizontal: 1.8° to 70.3°, Vertical: 1° to 37°, Diagonal: 2° to 69.3°
Optical Zoom 45x
Focus Control Auto, Manual
Close Focus Distance 100 mm to 3000 mm (3.94 in. x 118.11 in.)

PTZ

Pan/Tilt Range Pan: 0° to 360° endless
Tilt: –20° to 90°, Auto Flip 180°
Manual Control Speed Pan: 0.1° to 260° /s
Tilt: 0.1° to 120° /s
Preset Speed Pan: 300° /s
Tilt: 200° /s
Presets 300
PTZ Mode 5 Pattern, 8 Tour, Auto Pan, Auto Scan
Speed Setup Human-oriented Focal Length, Speed Adaptation
Power up Action Auto restore to previous PTZ and lens status after power failure
Idle Motion Activate Preset, Scan, Tour, or Pattern if there is no command in the specified period
Protocol DH-SD, Pelco-P/D (auto recognition)

Video

Compression Smart H.265+, H.265, Smart H.264+, H.264, MJPEG (sub stream only)
Streaming Capability Three (3) Streams
Resolution 4 MP (2560 x 1440), 3 MP (2048 x 1536), 1080p (1920 x 1080), 1280 x 960, 720p (1280 x 720), D1 (704 x 480), CIF (352 x 240)
Frame Rate Main Stream 4 MP, 3 MP, 1080p, 1.3 MP, or 720p at 30 fps, Sub Stream 1 D1, CIF at 30 fps, Sub Stream 2 1080p or 720p at 30 fps
Bit Rate Control CBR, VBR
Bit Rate H.265/H.264: 3 Kbps to 20480 Kbps
Day/Night Auto (ICR), Color, B/W
Backlight Compensation BLC, HLC, True WDR (120 dB)
White Balance Auto, ATW, Indoor, Outdoor, Manual, Sodium Lamp, Natural, Street Lamp
Gain Control Auto, Manual, Gain Priority, Shutter Priority,
Aperture Priority
Noise Reduction Ultra DNR (2D/3D)
Advanced Features Motion Detection, Region of Interest, Electronic Image Stabilization (EIS), Defog
Digital Zoom 16x
Flip 180°
Privacy Masking Up to 24 areas

Audio

Compression G.711a, G.711Mu, AAC, G.722, G.726, G.729, MPEG2-L2

Network

Ethernet RJ-45 (10 Base-T/100 Base-TX)
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Interoperability ONVIF Profile S and G, API
Streaming Method Unicast / Multicast
Max. User Access 20 users
Edge Storage NAS (Network Attached Storage), Local PC for instant recording
Micro SD Card Slot, maximum 256 GB
Web Viewer IE 10, Firefox
Management Software Smart PSS, DSS, DMSS
Mobile Operating System IOS, Android

Certifications

CE EN 55032, EN 55024, EN 50130-4
Electromagnetic Compatibility (EMC) FCC Part 15 Subpart B, ANSI C63.4-2014

Interface

Audio Input: One (1) Channel, Output: One (1) Channel
RS485 One (1)
Alarm Input: Seven (7) Channels, Output: Two (2) Channels

Electrical

Power Supply 24 VAC, 3 A (± 10%) or PoE+ (IEEE 802.3at)
Power Consumption 13 W, 26 W with IR on

Environmental

Operating Conditions –40° C to 70° C (–40° F to +158° F), Less than 95% RH
Ingress Protection IP67
Vandal Resistance IK10

Construction

Casing Metal
Dimensions 209.0 mm x 337.4 mm (8.23 in. x 13.28 in.)
Net Weight 5.90 kg (13.01 lb)
Gross Weight 9.60 kg (21.16 lb)

Analytics+ Functions

Perimeter Protection
Detects human or vehicle violations using the following methods:
Tripwire: a target crosses a defined line.
Intrusion: a target enters or exits a defined perimeter.
Video Structuralization
Distinguishes between motor vehicle, non-motor vehicle, and human targets.
Optimizes images and takes a snapshot of each target.

Intelligent Video System Functions

IVS triggers an alarm and takes a defined action for the following events:
Standard Features
Tampering with the camera.
Error writing to an onboard Micro SD card.
Error sending or receiving data over the network.
Unauthorized access to the camera.
Premium Features
Motion An object moves through any part of the scene.
Scene Change A person or object moves the camera to change the scene or covers the camera to obscure the scene.
Tripwire A target crosses a user-defined line.
Intrusion A target enters or exits a defined perimeter.
Abandoned/Missing Object A target leaves an object in designated area, or a target removes an object from the same designated area.
Advanced Features
Auto-tracking
Controls the pan/tilt/zoom actions of the camera to automatically track an object in motion and to keep it in the scene.
